Products and Services
 |
TraX Interconnect specialises in fast turnaround manufacture of PCBs for ontime delivery, ranging from simple Single sided & PTH to complex multilayer. TraX also offers single sided aluminium metal core boards, and the capability to manufacture copper metal core boards. TraX manufactures PCBs directly from customers’ designs (CAD data), we are able to receive CAD data in Gerber and ODB++ format. Send us your files now for a quotation. PCB TypesSingle sided Material TypesFR4 Tin-LeadTin lead, selectively applied over bare copper by “Hot Air Solder Levelling” Immersion TinMacdermid “MacStan” immersion tin is offered as a finish for very flat requirements such as BGA pads. This finish has a shelf life of at least 6 months prior to use. Electroless Nickel/Immersion Gold (ENIG)The Rohm and Haas process is used. This is also offered as a finish for very flat requirements such as BGA pads. Minimum nickel thickness is 4 microns, nominal gold thickness is 0.1 microns. Electroplated Gold over Nickel(for edge connectors)Minimum of 1 micron of electroplated hard gold alloy over 5 microns of electroplated nickel. Conductive CarbonElectra ED6000 conductive carbon ink is used to screen print keypads and other electrical contacts. Peelable SoldermaskElectra EM 55 Red peelable mask is applied by silkscreen to selectively mask circuit features as required. |
